7" IPS TFT touch display module, 800×480 (JM-ZH601-00)
- Model
- JM-ZH601-00
- Size
- 7"
- Brand
- Junxian Display
- Place of origin
- Shenzhen, China
- Sample MOQ
- 5 pcs
- Production MOQ
- 100 pcs (standard) / 1,000 pcs (fully custom)
- Lead time
- 10-20 days
- Payment
- T/T, L/C, PayPal
- Trade terms
- EXW, FOB Shenzhen, CIF
Specifications
Model JM-ZH601-00, built in our Shenzhen plant - 350 cd/m² brightness. Sample MOQ is 5 pcs, production MOQ 100 pcs, and lead time 10-20 days once the specification is frozen.
| Model number | JM-ZH601-00 |
|---|---|
| Screen size | 7" |
| Resolution | 800×480 |
| Display type | IPS |
| Interface | USB/RS232/RS485 |
| Brightness | 350 cd/m² |
| Colours | 16.7M |
| Touch panel | Resistive Touch Screen |
| Driving voltage | 6-25V |
| Backlight | LED White Light |
| Backlight lifetime | 40,000 Hours |
| Outline dimension | 211.0mmx150.0mmx24mm |
| Active area | 153.84X85.63mm |
| Storage temperature | -20°C to +70°C |
| Compliance | REACH & RoHS Compliant |
Typical values at 25 °C. Tolerances, pin assignment and timing are in the datasheet — ask for it before locking your PCB layout.
Price depends on quantity, touch option and packaging. Send the quantity and we quote the same working day where possible.
Mechanical drawing
Outline, active area position, FPC route and pin pitch. Dimensions in millimetres. Check this against your enclosure opening before you commit the mechanical design — it is free to change here and expensive to change after tooling.
Drawing carried over from our previous catalogue; some annotations are in Chinese. Ask us for the current 2D drawing (DWG or PDF) and we will send it with the datasheet.
Product description
Custom high-performance 7-inch LCD display with 4-wire industrial resistive touch screen with adjustable brightness for industrial equipment
JM-ZH601-00, a high-performance 7.0" TFT LCD HMI designed for industrial applications. Boasting a crisp 800×480 resolution and 16-bit color, it delivers vivid visuals across a 153.84mm×85.63mm effective area.
Product Features
Powered by an ARM9 300MHz RISC CPU with 64MB DDR2 + 128MB Flash, it offers robust performance. Equipped with 2 RS232/RS485 ports, 1 USB Slave 2.0, 1 USB Host 2.0, and optional 10M/100M Ethernet (COM2 disabled when Ethernet is selected), it ensures flexible connectivity.
DC 6~25V input (24V rated) with reverse protection and <5ms power loss tolerance enhance reliability.
Product Specifications:
Key specs include a 4-wire industrial resistive touchscreen, 350 cd/m² brightness (customizable), and long-lasting LED backlight with 50,000-hour lifespan. Its wide viewing angles (70°/70°/60°/70° for T/B/L/R) ensure clear visibility from various positions.
Detail photos
