3V COG Monochrome Character LCD Display Module SPI LCD Monitor For Consumer Electronics
- Model
- JM-1602-06
- Brand
- Junxian Display
- Place of origin
- Shenzhen, China
- Sample MOQ
- 5 pcs
- Production MOQ
- 100 pcs (standard) / 1,000 pcs (fully custom)
- Lead time
- 10-20 days
- Payment
- T/T, L/C, PayPal
- Trade terms
- EXW, FOB Shenzhen, CIF
Specifications
Model JM-1602-06, built in our Shenzhen plant - 150 cd/m² brightness, ST7567 driver IC. Sample MOQ is 5 pcs, production MOQ 100 pcs, and lead time 10-20 days once the specification is frozen.
| Model number | JM-1602-06 |
|---|---|
| Interface | SPI Serial Port |
| Brightness | 150 cd/m² |
| Colours | Blue,green,white Or Customizable |
| Driver IC | ST7567 |
| Backlight | LED White Light |
| Backlight lifetime | 40,000 Hours |
| Outline dimension | 73.00X26.00X6.20mm |
| Active area | 64.60X16.00mm |
Typical values at 25 °C. Tolerances, pin assignment and timing are in the datasheet — ask for it before locking your PCB layout.
Price depends on quantity, touch option and packaging. Send the quantity and we quote the same working day where possible.
Mechanical drawing
Outline, active area position, FPC route and pin pitch. Dimensions in millimetres. Check this against your enclosure opening before you commit the mechanical design — it is free to change here and expensive to change after tooling.
Drawing carried over from our previous catalogue; some annotations are in Chinese. Ask us for the current 2D drawing (DWG or PDF) and we will send it with the datasheet.
Product description
Custom & OEM 3V COG Monochrome LCD Monitor COG Dot Matrix Display Fit For Consumer Electronics Portable Devices
Definition and Principle
COG Dot Matrix Display refers to a type of display technology that uses a Chip - on - Glass (COG) packaging method for dot - matrix - style displays. Here is a detailed introduction:
Principle
It consists of a matrix - arranged array of pixels, and each pixel can be independently controlled to display different colors or grayscale levels. By controlling the on - off state and brightness of these pixels, various images, text, and graphics can be presented.
Product Key Features and Advantages
(1) Reliable Drive IC:Powered by the Sitronix ST7032 IC, this 16×2 monochrome character LCD display module guarantees stable operation, minimizing the risk of malfunctions and ensuring consistent performance over time.
(2) Energy-Efficient Power Supply: Operating at a low 3.0V power source, it stands out for its energy efficiency. This makes it an ideal choice for battery-powered devices, extending battery life, and is adaptable to various power configurations, enhancing its versatility.
(3) Display Quality: Delivers high-clarity character display with a uniformly colored background, ensuring information is easily readable. Its programmable display direction offers flexibility to meet different installation and viewing requirements. Supporting the display of English characters and graphic symbols, it caters to a wide range of informational display needs. Moreover, its straightforward programming simplifies operation, reducing the learning curve for users.
(4)Convenient Interface: Fitted with an SPI serial port, which can be effortlessly configured through both software and hardware. This enables seamless communication with other devices, facilitating quick integration into diverse systems and projects.
(5) Wide Temperature Adaptability: Can function flawlessly in environments ranging from -20°C to 70°C and be safely stored between -30°C and 80°C. This broad temperature tolerance makes it suitable for use in various indoor and outdoor settings, from cold storage facilities to sunny outdoor applications.
Detail photos
What this specification means in practice
150 cd/m² is an indoor, low-power specification - typical for battery meters and handheld instruments where runtime matters more than brightness.
SPI keeps the wiring to four or five lines, which is why it dominates small colour displays on 32-bit MCUs. The trade-off is refresh rate on larger resolutions.
Ordering and customisation
This model ships as a bare module by default. We commonly modify the FPC length and connector, change the backlight current, add a capacitive or resistive touch panel, or bond cover glass with your printing. Tell us the enclosure opening and the mounting method and we will confirm what can stay standard and what needs tooling.
Typical applications
Industrial Automation & HMI
Status lines on controllers and drives - two or four rows of text is often the entire UI requirement.
Instrumentation & Metering
Bench equipment and test rigs where a standard 16x2 module keeps BOM cost and firmware effort minimal.
How a customised order runs
Send the requirement
Size, resolution, interface, brightness, operating temperature, touch or no touch, and the annual quantity. A photo or drawing of the enclosure opening helps more than a long description.
We confirm feasibility and quote
You get a specific model number or a modification plan, with tooling cost and lead time stated separately from the unit price. Usually within one working day.
Sample and approval
Samples in 10-15 days from stock glass; custom glass or a new FPC adds tooling time. You approve dimensions, display quality and interface timing before mass production starts.
Production and shipment
10-20 days after specification freeze. Anti-static bag + foam tray + export carton, shipped DHL / FedEx / UPS express or by your forwarder. We keep the approved sample as the reference for every repeat order.
Related models
3.3V 5.0V Character LCD Modules 16 PIN LCD Display Monochrome Multiple Sizes
8x2 Character LCD Module ST7066 Blue Monochrome LCD Display Multiple Sizes
3.2 Inch Character LCD Modules High Contrast LCD Display 100cd/m2 With Wide Viewing Angle
Custom 20x2 Character LCD Modules Blue Yellow Green Display With I2C/SPI/6800 LCD Interface
Questions about this model
What is the minimum order quantity for the JM-1602-06?
Samples are 5 pcs. Production MOQ is 100 pcs for this catalogue model and 1,000 pcs when the FPC, backlight or glass is modified.
How long is the lead time?
10-20 days for production quantities, 10-15 days for samples from stock glass. Custom tooling is quoted separately and confirmed in writing first.
Can this module be customised?
Yes - FPC length and pin order, connector type, backlight brightness and colour temperature, cover glass, touch panel and bonding method. See what is changeable.
Do you provide a datasheet and drawing?
Yes. Email hyd@szjunxian.com with the model number and we send the full datasheet, 2D drawing and, where relevant, the initial sample report.
Which interface should I choose for my board?
It depends on your host processor and target resolution. Our interface selection guide compares MCU, SPI, RGB, LVDS and MIPI by pin count, resolution ceiling and MCU load.
Packaging, shipping and trade terms
Packaging is anti-static bag + foam tray + export carton, shipped by DHL / FedEx / UPS express, air freight, sea freight. Trade terms EXW, FOB Shenzhen, CIF, payment T/T, L/C, PayPal.
Need this module with different parameters?
Most orders start from a catalogue model and change two or three parameters. Send us the differences you need and we will confirm feasibility, tooling and price.
